Rail Welding Machines and Track Machinery

KZESO develops and manufactures flash-butt rail welding equipment for field and stationary applications — from welding heads and complete machines to containerised systems and mobile road-rail welding complexes.
Built on rail welding expertise dating back to 1959 and proven through operation in more than 100 countries, KZESO combines equipment, engineering and lifecycle support to help railway projects achieve reliable welding performance and long-term equipment availability.

Explore Products Discuss Your Project

Mobile Rail Welding Machines
Mobile flash-butt rail welding machines for welding directly on track. The range covers different upsetting and clamping forces, upsetting strokes and application requirements, allowing the equipment to be matched to specific field-welding conditions.
● K900A-1● K900T● K920● K922-1● K930/K945/K950/K955● K1067

Stationary Rail Welding Machines
Stationary flash-butt rail welding machines for rail-welding plants and specialised production applications. K1000 and K1100 are designed for stationary rail welding, while K924 is intended for specialised welding of railway crossing components and associated rail parts.
● K1000● K1100 ● K924

Containerised Rail Welding Solutions
Integrated containerised rail welding systems. A single transportable module combines the welding equipment with the required auxiliary systems — hydraulics, cooling, controls, autonomous power and handling equipment — according to the selected configuration. Containerised execution is available for applicable KZESO machines except K924.
● K924

Mobile Rail Welding Complexes
Complete mobile rail welding complexes integrating rail welding equipment, a transport platform, rail-running system, power generation, hydraulics, cooling, controls and welding-machine handling equipment. The principal solution in this category is KCM007.
● KCM007

Road-Rail Vehicles
Specialised road-rail vehicles designed for operation on public roads and railway track and for integration of specialised equipment. This category includes VHD-2.
● VHD-2

Other Specialised Equipment
Additional KZESO specialised equipment for rail-welding production and railway infrastructure. The range includes the KPM Press for Testing Welded Rail Joints and KZF 11 / KZF 13 contactors.
● KPM Press

Mobile Flash Butt Rail Welding Machine К922-1

The K922-1 welding machine is designed for flash-butt welding both by pulse and continuous flashing of rails with cross section area from 6500 mm² up to 12000 mm² with flash removal immediately after welding.
The K922-1 welding machine can be used both as part of mobile rail welding installations and in stationary conditions.

Learn more

Mobile Flash Butt Rail Welding Machine K930, К945, K950, К955

The welding machines are designed for flash-butt welding both by pulse and continuous flashing of rails with increased stroke of upset rods (to ensure the pulling of the rails), with cross section area from 6500 mm² up to 12000 mm² with flash removal immediately after welding.
Currently, the company produces new generation machines K930, K945, K950, K955.

Learn more

Mobile Flash Butt Rail Welding Machine К1067 (for railway switches)

The K1067 rail welding machine is designed for contact butt welding of railway switches with welded rail ends to railway rails and railway rails between themselves, as well as for welding in hard-to-reach places.
K1067 is also used for welding rails that are placed at a close distance from each other on railways and subway lines.

Learn more

Stationary Flash Butt Rail Welding Machine K1000

The K1000 welding machine is designed for stationary flash-butt welding of rails with cross-section area of rails from 5000 mm² to 10000 mm² with flash removal immediately after welding.
According to the special order it can be manufactured for welding of other profiles with section area up to 18000 mm².

Learn more

Stationary Flash Butt Rail Welding Machine K1100

The machine is a re-equipped version of K1000 machine due to the need to weld the alloy steel rails, as well as to weld rail sections comprising isolated joints.
The K1100 welding machine is designed for stationary flash-butt welding of rails with cross-section area of rails from 5000 mm² to 10000 mm² with flash removal immediately after welding. According to the special order it can be manufactured for welding of other profiles with section area up to 18000 mm².

Learn more

Stationary Flash Butt Rail Welding Machine K924 (for railway switches)

The K924 welding machine is designed for stationary flash-butt welding of the elements of the railway switches made of special steel to the appropriate rail ends or for welding rails with height of 140-195 mm and cross section area up to 15000 mm²., with flash removal immediately after welding.

Learn more

Mobile Container Complex based on the K1100 rail welding machine

The autonomous container complex on the basis of the K1100 rail welding machine is designed for welding of the rail strings under field conditions. It can be transported by road to the construction site of the railway and work in any climatic conditions.

Learn more

Mobile Container Complex based on the K922-1 rail welding machine

The autonomous container type welding complex on the basis of the K922-1 rail welding machine is mounted in the container and designed for installation on a railway platform or vehicle.

Learn more

Mobile Road-Rail Container Complex KCM

The КСМ007 is manufactured on the Volvo automobile chassis, equipped with two bogies with their individual hydrostatic drive and the K922-1 rail welding machine. The complex is designed for the rail welding under field conditions at construction and repair of the rail tracks and tramlines.

Learn more
